Coupling of two independent CAN networks via LAN/internet bridge over two seperate devices.Several simultaneous network connections (5x TCP and 1x UPD) are supported on each existing CAN interface.4 digital inputs and outputs, which can be accessed via LAN/Ethernet.Static or dynamic assignment (DHCP) of IP address.System is addressed using a proprietary network protocol.Two different plugs for voltage supply.Software configurable bus termination for each CAN interface.This can be done using a device that supports TCP sockets (like a personal computer or a PLC). The AnaGate CAN duo can send and receive CAN messages via both existing CAN interfaces independantly.The AnaGate CAN uno do not support this so called internal bridge mode. Features The AnaGate CAN duo and AnaGate CAN quattro can additionally interconnect two internal CAN interfaces.
With the coupling over LAN/Ethernet it is possible to connect separate CAN buses with different baud rates over long distances. In bridge mode the AnaGate CAN Gateway can interconnect two physically independent CAN networks via LAN/Ethernet (LAN bridge mode). The libraries includes the entire range of device functions and can be used with conventional programming languages. Accessing the device with the supplied application libraries for Windows and Linux is much comfortable.
This means that any communication partner with a LAN interface is able to communicate to the device. Thus the access to the device can be programmed via native calls to the TCP/IP socket interface. The application protocol itself is described in detail (see ). Controlling and configuration of an AnaGate CAN Gateway is made through TCP/IP. For this reason the AnaGate CAN duo provides an ethernet interface and two independent electrically isolated CAN interface. It basically works as a CAN master with no own CAN identifier on the bus. Description The AnaGate CAN Gateway connects a PC, an embedded PC or an other general device to one or more CAN busses via the TCP/IP network protocol. Otherwise the full product name is used, like AnaGate CAN USB, AnaGate CAN uno, AnaGate CAN duo or AnaGate CAN quattro. In this manual the term AnaGate CAN Gateway is uniformly used, if no specific model is addressed or it is not necessary to differentiate. This device is part of a product line, whose single devices only differ in the number of CAN interfaces and/or the device case. Introduction This document describes the features and objectives of the CAN-Ethernet gateway AnaGate CAN duo.
